LED Asymmetric Flood Light | Wattage and 3CCT Adjustable | 120w | 240w | 500w

SKU: DM-ASYMMETRIC-FLOOD

Price range: £89.00 through £259.00 ex. VAT (£106.80 inc. VAT)

Clear
Qty:

The Asymmetric LED Flood Light is a professional-grade lighting solution specifically engineered for stadium and sports facility lighting, as well as demanding commercial and industrial outdoor environments. Its precision asymmetric optics make it particularly suitable for football pitches, rugby grounds, training facilities, tennis courts, multi-use games areas (MUGAs), athletics tracks, and spectator stands, where controlled light distribution, reduced glare, and uniform illumination are critical for both players and spectators.

Equipped with high-efficiency Lumileds 2835 LED chips and a dependable Meanwell driver, this floodlight delivers up to 150 lumens per watt, ensuring powerful illumination with reduced energy consumption. The adjustable wattage functionality allows precise output control across all variants: 120W (80W/100W/120W), 240W (150W/200W/240W), and 500W (300W/400W/500W), making it suitable for everything from community sports grounds to large-scale stadium installations.

The integrated 3CCT selectable colour temperature (3000K, 4000K and 5000K) enables compliance with varying sports lighting standards, providing warm tones for training areas and crisp, high-clarity light for competitive play and broadcast-ready environments. A 90° asymmetric beam angle ensures light is directed onto the playing surface, minimising spill light, improving uniformity, and reducing glare for athletes, officials, and spectators.

Designed for reliability in exposed conditions, the fitting features an IP66 weatherproof rating, IK08 impact resistance, and stable operation from -25°C to +50°C. With a 50,000-hour lifespan, high power factor (>0.95), 5-year warranty, and CE & RoHS certification, the Asymmetric LED Flood Light delivers long-term performance for modern stadium, sports, and large-area outdoor lighting projects.

Description

Technical Data:

Chips and driver Type Lumileds 2835 Chips + Meanwell driver
IK Rating IK08
Wattage: 120w: Adjustable 80w, 100w, 120w

240w: Adjustable 150w, 200w, 240w

500w: Adjustable 300w, 400w, 500w

Lumens: 150lm/W
Colour Temperature: 3CCT Selectable: 3000K, 4000K and 5000K
Working Temperature: -25°+50°
Beam Angle: 90°
Voltage input: 100-277V
Lifespan: 50,000 Hours
Rating: IP66
CRI: >80
Power Factor: >0.95
Warranty: 5 years
Dimensions 120w: 303mm x 356mm x 70mm

240w: 364mm x 421mm x 70mm

500w: 364mm x 421mm x 70mm

Certificates: CE & RoHS
Application:

Designed for precision lighting, it is ideal for football pitches, rugby grounds, training facilities, tennis courts, multi-use games areas (MUGAs), athletics tracks, and spectator stands, car parks, logistics yards, building facades, construction sites, and perimeter lighting

Download Datasheet

Additional information

Power

120w, 240w, 500w
